Mini-Mac Applicator for Flat Blade Crimp Terminals
CRIMP SPECIFICATIONS
Terminal Series No.
Bell mouth
mm In.
Cut-off Tab Max.
mm In.
Conductor Brush
mm In.
1508
Terminal Series No.
1508
Bend up Bend down
Degree
Twist Roll
Degree
Punch Width (Ref)
Conductor Insulation
mm In. mm In.
2.30 .091 4.25 .167
Seam
Seam shall not be open and no wire allowed out of the crimping area
After crimping, the conductor profile should measure the following.
Terminal Series No.
Wire Size
Conductor
Crimp Height Crimp Width (Ref.)
Pull Force
Minimum
AWG
mm 2
mm In. mm In.
N Lb.
1508
20 + 20
0.50+ 0.50
1.52-1.62 .060-.064 2.32-2.42
.091-.095
57.8 13.00
NOTE : Some of the specifications in these charts above are intentionally left blank due to the fact that the
information does not currently exist.
Tool Qualification Notes:
1. Pull Force should be measured with no influence from the insulation crimp.
2. The above specifications are guidelines to an optimum crimp.
Doc No: ATS-638941200 Release Date: 07-29-09
Revision: C Revision Date: 09-06-10
UNCONTROLLED COPY
Page 2 of 5
